Optical System |
Infinite Optical System |
||||
|
Viewing Head |
Trinocular Head Inclined at 30°,Interpupillary 48-75mm |
||||
|
Eyepiece |
High-point, Extra Wide Field Eyepiece EW10X/ 22 |
||||
|
Nosepiece |
Quintuple Nosepiece |
||||
|
Objective |
LWD Infinite Plan Objective |
4X/0.1, WD18mm |
|||
|
10X/0.25, WD10mm |
|||||
|
20X/0.4, WD5.1mm |
|||||
|
40X/0.6, WD2.6mm |
|||||
|
Infinite Plan Phase Objective |
PH 10X/0.25, WD10mm |
||||
|
PH 20X/0.4, WD5.1mm |
|||||
|
PH 40X/0.6, WD0.35mm |
|||||
|
Infinite Plan Fluorescent Objective |
4X, 10X, 20X, 40X |
||||
|
Condenser |
ELWD Condenser NA 0.3, LWD 72mm |
||||
|
Focusing |
Coaxial Coarse and Fine Adjustment, Vertical Objective Movement, Coarse Stroke 37.7mm per rotation, Fine Stroke 0.2mm per rotation |
||||
|
Stage |
Plain stage 160X250 mm, Attachable Mechanical Stage 80X120mm |
||||
|
Illumination |
Halogen Lamp 6V/ 30W |
||||
|
Filter |
Blue/Green and Ground Glass (ф45mm) |
||||
|
Phase Annulus |
|
||||
|
Centering telescope |
|
||||
|
Photo Attachment |
|
||||
|
Video Adapter |
Video Adapter with C Mount |
||||
|
Reflected Light Source |
|
Excitation |
Dichroic Mirror |
Barrier Filter |
|
|
Blue excitation |
BP460~490 |
DM500 |
BA520 |
||
|
Blue excitation(B1) |
BP460~495 |
DM505 |
BA510~550 |
||
|
Green excitation |
BP480~550 |
DM570 |
BA590 |
||
|
Ultraviolet excitation |
BP330~385 |
DM400 |
BA420 |
||
|
Violet excitation |
BP400~410 |
DM455 |
BA455 |
||
|
Lamp |
100W HBO Ultra Hi-voltage Spherical Mercury Lamp |
||||
|
Protection barrier |
Barrier to Resist the Ultraviolet Light |
||||
|
Power Supplier |
Power Supplier NFP-1, Wide range of voltage 100-240V, Digital Display |
||||
|
Immersion Oil |
Fluorescent Free Oil |
||||
|
Neutral ND25/ ND6 Filter |
|
||||
|
Centering Plate |
|
||||
